Features:
- EPA Certified fuel consumption l/h – 0
- System weight kg 1) – 12.57 / 13.23 / 14.24
- Oil tank volume cm3 – 700
- Oil pump – Adjustable
- STIHL Oilomatic saw chain pitch/type – .404″ Rapid Super
- Maximum RPM 1/min 2) – 11.000
- Vibration values left/right m/s² 3) – 8.9/8.9
- Filler cap – Tool-free filler cap
- Sound power level dB(A) 4) – 118
- Chain pitch – .404″
- Bumper spike – 2 Steel claws
- Speed at maximum power Um – 8.500
- Weight kg 5) – 9.9
- Anti vibration system – Standard AV-System
- Cylinder – Chrome
- Sound pressure level dB(A) 4) – 106
- Tank volume l – 1.30
- Performance kW – 6.4
- Chain tensioning – Lateral chain tensioning
- Filter – HD2 filter
- Sprocket – number of teeth – 7 Z
- Displacement cm³ – 121.6
- Sprocket – Ring sprocket
- Power-to-weight ratio kg/kW – 1.5
- Power output kW/bhp – 6.4/8.6
1) Unfueled, with guide bar and saw chain
2) Einstellwert mit Schneidgarnitur für Service
3) K-factor according to DIR 2006/42/EC = 2m / s ²
4) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
5) Without fuel, without bar and chain
